Portfolio

Featured Projects

Development of Printed RFID NFC Antenna

Capture130

RF Antenna Design, Printed Electronics, Wearable Electronics, RF Simulation, Custom Test Fixture, Quick Turn

Development of Custom Microwave Doppler Sensor

Features RF simulation, custom firmware, PCB antenna design, prototyping, custom PCB, Bluetooth 5.0

Development of Inertia Measurement Systems

Features, High-g accelerometer chip, low-g IMU, 32bit high-performance microcontroller, flexible PCB sensors, user interface, data acquisition systems

Portfolio of Projects

Capture128
Battery Powered Rotation Counter with LCD Character Display

Keeps track of hundreds of directional changes and speeds up to 1,000 RPMs while having years of battery life and a LCD character display. Custom firmware, PCB layout

Capture129
Advanced 6-Sensor Data Acquisition Motherboard with Wifi and SD Card Data Logging

Logs up to 200G impacts across 6 sensors and pushes data to a PC interface for evaluation. Custom PCB system, PC interface and firmware

Capture130
Printed Ink NFC Tag

Communicates to mobile devices up to 16 mm, Coil design using RF simulation software

Capture131
Proximity Sensor Detects Objects as They Pass Through the 3D Printed Chamber

Triggers alarms when a certain size object passes through this chamber, auto-calibrated, LED indicator light, custom firmware and PCB design

Capture136
Wireless Battery Charger for Kitchen & Bath Goods

Device wirelessly charges from its docking station, on/off motor controller, LED indicator lights, high volume commercial product design,

Capture137
Custom Production Test Fixtures

Tests all facets of the circuit board quickly and accurately

Capture138
OSHA Backup Alarm System for Large Mining Equipment

Manages power delivery to large engine starter relays, configurable timers via jumper settings, automotive power supply rated, robust, waterproof, custom firmware and PCB design

Capture139
High Pressure Monitoring Device

Absolute pressure sensor digitizes pressure data and sends data via strain-relieved cable

Capture132
Flex Sensor Data Acquisition System

Multi-layer rigid flex sensor design, high speed SPI, custom motherboard, PC interface, daisy-chain capable design

Capture133
Invisible Trip-Wire Using Doppler Sensor Technology

Detects the speed and direction of incoming objects using 10GHz doppler technology, 270 degree detection, Bluetooth alarm functionality, custom software, custom PCB design

Capture134
Quick-Turn Ultrasonic Sensor Engineering Breadboard

Detects objects up to 15ft away and streams sensor data to a PC interface, custom software, custom firmware

Capture135
Bluetooth/Wi-FI Enabled Sensor Array

Reads from an array of force and temperature sensors and streams values to a PC and mobile interface, lipo battery powered, multiplexed analog front end, custom software and PCB layout

Capture124
Retro Novelty TV Remote for B2B Advertising Campaign

Produced several hundred devices in-house, fast turn time, audio, SD card, DSP microprocessor, custom firmware and PCB design

Capture125
Custom Cable Production

Full turn-key cable solution, quick turn, high quality, fully tested

Capture126
1.8” Custom Sensor Display with Bluetooth

Senses motor direction and RPM, controls motor speed via turnpot, Bluetooth controls, 12-24V compatible, custom firmware and PCB design

Capture127
Counting Motor Rotation Using a Magnet and Hall Sensors

Counts the number of motor rotation and remembers the position of the motor through a power reset, custom firmware and PCB design

Capture120
Wireless Remote Control for changing Volume, Taking Pictures, and Switching Apps for Android and iOS

Lipo battery powered, rechargeable, Bluetooth Low Energy communication, custom PCB

Capture121
Temperature Measurement Circuit for Diabetics

Bluetooth Low Energy, temperature sensing, coin cell operation, custom software and PCB design

Capture122
Ethernet Temperature and Humidity Sensor Device for Vacant Property Managers

Industry 4.0, Cloud data storage, DIN rail mount, custom software/firmware and PCB design.

Capture123
Industrial Temperature Sensor

1-wire digital communication, high accuracy, custom PCB design, PC test software

Capture94
Force Sensor Bluetooth Data Logger

Flex-PCB, temperature and pressure sensors, datalogger, MUX inputs, rechargeable battery, custom PCB, custom software, Bluetooth interface

Capture95
Nordic Bluetooth e-Paper (e-Ink) Display Driver

E-paper display driver, PCB antenna design, 80KV human body tested, FCC compliant, custom PCB, custom firmware

Capture96
7-Segment LED Display Driver for Motion Capture Device

LED driver, battery powered, numerical display, custom PCB, custom firmware, PCB production

Capture97
Analog Front End for Printed Ink Sensor

Force sensor analog front end, auto-offset calibration, EEPROM for storing linearization equations, PC interface, RGB array, battery powered, Bluetooth enabled, custom PCB, custom software, custom firmware

Capture90
High G Single Axis Impact Data Logger

Detects impacts, stores data before and after impact, powered by super capacitor, free-fall detection, custom PCB, custom firmware

Capture91
Vacuum Cleaner LED display

Consumer volume PCB design, jumper settings for different light modes, USB powered test board, custom PCB

Capture92
Automotive Entertainment System Control Board

Rapid turn-time, audio driver, LED driver, wireless Qi charger design, dimmable LEDs, AC inverter, custom PCB

Capture93
Indoor Tracking Device

Tuneable 900MHz antenna, AC/DC power supply, PC-based location software, triangulating sensor position, custom PCB, custom firmware

Capture86
Bluetooth Repeater for Police Cruiser Light Bar

Dual bluetooth repeater, drives settings on police cruiser light bar, communication between nearby cruisers, custom PCB, custom firmware, light PCB production

Capture87
Long Range 900MHz RF Transmitter

Bluetooth commands via mobile app transmitted over long range 900MHz RF link, handheld device, custom PCB, FCC compliant, custom PCB, custom firmware

Capture88
High Voltage AC Motor Driver and Timer

Jumper settings set motor timing, push buttons start/stop/pause the sequence, AC/DC power supply design, custom PCB, custom firmware

Capture89
7-Segment LED Display Driver for Motion Capture Device

LED driver, battery powered, numerical display, custom PCB, custom firmware, PCB production

Capture82
Signal Integrity PCB

Testing the limitations of high speed SPI communication bus, prototype, proof-of-concept, custom PCB, custom firmware

Capture83
Force Sensor Data Logger

4-Channel resistive force sensor data logger, PC interface for calibration, custom PCB hardware, custom firmware

Capture84
Optically Isolated Motor Controller

PLC driven motor driver, opto-isolated digital and analog signals, jumper settings for different motor types, custom PCB, custom firmware

Capture85
Automotive Bluetooth Controlled Police Light Bar

Driver for police cruiser light bar, individually controllable light settings, Bluetooth enabled, automotive power supply, custom PCB, custom firmware, PCB production

Capture78
TMD 08 - LowG

Desktop Client Application – Calibration summary tab

Capture79
TMD 08 - LowG

Desktop Client Application – Calibration process window

Capture80
200G High Speed Accelerometer

High speed digital buffer for 200G accelerometer IC. Custom PCB, custom firmware, 6-layer PCB design, compact design

Capture81
Dual Accelerometer Motion Capture PCB

High G and high speed low G accelerometer motion capture PCB, custom hardware, custom firmware, PC interface

Capture32
Compact Power Delivery

Intelligent power supply for low resistance heaters, custom PCB, custom firmware, user interface

Capture33
Custom Motor Encoder

Hall sensors, detects rotation of a magnet, 12V operation, custom PCB, custom cable harness, production order

Capture34
Wifi Window Shade Controller

Wifi radio, 12V operation, 12W bi-directional motor driver, RGB LED feedback, up/down/stop/program inputs, custom PCB, custom firmware

Capture35
High Speed IMU DAQ

Connect up to 6 IMU sensors, logs data before and after impact, SD card, Wifi, high speed SPI, battery powered, custom PCB, custom software

Capture28
LED Lighting

LED driver, 12V operation, reverse polarity protection, custom PCB design

Capture29
Illuminated Collar

Battery powered LED driver, push button

Capture30
Industrial Illuminated E-stop Button

Custom LED PCB lights LED when E-STOP is pressed, power scavenge circuitry, compact design

Capture31
Battery Powered Nebulizer Driver

Humidifier piezo driver, lid open/close detection, simple interface, USB battery powered, custom PCB, custom firmware

Capture24
Cellular USPS Automobile Tracker

Cellular module, CAN-LIN communication enabled, custom firmware, custom hardware

Capture25
Multi-layer Rigid Flex Bluetooth Printer Sensor Interface

Analog front end for conditioning force sensor signals, Bluetooth to mobile apps, USB battery charging, custom PCB, custom software

Capture26
Reverse Engineering

Extremely high volume PCB design, wire bonding, system on board design

Capture27
Motor RPM Gauge + Stepper Motor Driver

Read signals from engine tachometer, automotive power supply, server controller, position feedback, custom PCB, customer firmware

Capture20
Reverse Engineering Optocoupler Control PCB

Reverse engineering, 24V operation, 10+ year production lifetime, pilot production run, custom PCB

Capture21
Muscle-wire Parachute Driver

Long range RF control, closed-loop muscle wire controller, temperature feedback, battery powered, custom PCB, custom firmware

Capture22
300W DC Motor Controller

Automotive power supply rated, DC pump control, OLED display, user interface, custom PCB, custom software

Capture23
Confidential

Multilayer flex PCB, power control feedback, mini color OLED display, user interface, battery powered, custom PCB, custom firmware

Sensorless Brushless DC Control Board

Wide operating voltage range, Input voltage: 50-250VAC, Current capability: 1-5A, Speed range 1000 to 120000 RPM

Capture17
Battery Powered Two-Way 900MHz Radio

Custom PCB trace antenna, battery powered, long life, custom PCB, custom firmware

Capture18
400 Watt Brushless DC Motor Controller

Wide operating range, 12-24V input, 35A current capability, 7,000 RPM, custom PCB, custom firmware

Capture19
Bluetooth + Long Range 900MHz Telemetry Radio

Long range RF, rechargeable battery powered, Bluetooth to laptop communication, Windows 10 GUI interface, manufacturing contract, custom PCB, custom firmware, custom software

Wearable Bluetooth Password Storage Dongle
PCB design, Embedded firmware, Security audited by a third party company, Remote freeze (for temporary deactivation), AES 128-bit encryption, AES 256-bit encryption, RSA 4096-bit encryption, Spoof prevention
Wearable Bluetooth Wristband
Pilot production run, high volume consumer design, RGB LEDs, vibrating motor, Bluetooth, user interface, App interface, embedded firmware, custom PCB
Successful with IoT Industry 4.0
WiFi, Ethernet, USB PC interface, 10x 0-24V inputs, 10x 0-24V outputs, 250mA current limited outputs, 10x 4-20mA inputs, 10x 4-20mA outputs, embedded software, custom PCB, low volume PCB production
Motion Sensor and Alarm System
Bluetooth, high brightness LEDs, metal core PCB, doppler sensor, battery powered, siren, user interface, embedded firmware, custom PCB
Miniature Heater Element
Temperature sensor, resistor as heating element, pogo-pin interface, RC network, production volume greater than 1M pieces per year, custom PCB, production
Bluetooth Accelerometer Data Logger
Battery powered, accelerometer, battery powered, Bluetooth, embedded firmware, custom PCB, production
LED Level Gen 1

LED driver, user interface, battery powered, high volume consumer product, accelerometer, embedded software, custom PCB

Motion Stabilized Camera

9-axis IMU, high voltage input, RS232 interface, 3x brushless DC motor controller, embedded firmware, custom PCB

Wearable Early Alert System
Wearable Bluetooth alarm, high brightness flash LEDs, vibrating motor, RGB LEDs, battery powered, Bluetooth radio, custom firmware, custom PCB
Photo-Interrupt Sensor

PCB for mounting sensors, custom cable harness, custom PCB

Wearable Bluetooth Vibrating Wristband

High volume, RGB LEDs, vibrating motor, Bluetooth, user interface, App interface, embedded firmware, custom PCB

Miniature Heater Element

Temperature sensor, resistor as heating element, pogo-pin interface, RC network, production volume greater than 1M pieces per year, custom PCB, production

Waterproof Vibration Sensor
Bluetooth, motion sensors, IMU, battery powered, USB, high volume, DSP, embedded firmware, custom PCB
Air Pressure Monitor
Pressure, humidity, and temperature sensor, datalogger, embedded firmware, custom PCB
Bluetooth Accelerometer Data Logger

Battery powered, accelerometer, battery powered, Bluetooth, embedded firmware, custom PCB, production

Power Distribution PCB
Power management, DC/DC converter, USB power supply, custom PCB
Low Cost Character LCD Display Project

LCD display, user interface, datalogger, embedded software, custom PCB

Pressure Sensor Data Logger

EEPROM memory storage, analog front end, low power, embedded software, custom PCB

High Volume Greeting Cards

Single layer PCB, chip-on-board wire bonding design, low cost BOM, custom PCB

Motion Sensor Data Logger

Accelerometer, data logger, SD card, Bluetooth, battery powered, PC software, embedded software, custom PCB

Automotive Power Supply for a CAN bus Computer

Power supply design, CAN bus, OBD port, power management, custom PCB

CAN bus Monitor

Data logger, Bluetooth, OBD port, automotive power supply, SD card, embedded firmware, custom PCB

Bluetooth Air Quality Sensor

USB interface, Bluetooth, analog front end, battery backup, embedded firmware, custom PCB

9-axis IMU Glove Motion Sensors

IMU sensors, micro electronics, flex PCB, custom cable harness, embedded firmware, custom PCB

IoT Strain Gauge and Motor Driver PCB

Web interface, strain gauge, analog front end, Ethernet, microprocessor, H-bridge DC motor driver, real time streaming, embedded firmware, custom PCB

Battery Powered Bluetooth Motion Sensor

Battery powered, Bluetooth, real-time sensor streaming, high speed, motion sensor, embedded firmware, custom PCB

Stepper Motor Carousel Control PCB

User interface switches, thermal feedback, stepper motor control, embedded firmware, custom PCB

Miniature Real Time USB Motion Sensor

USB, real-time sensor streaming, high speed, motion sensor, embedded firmware, custom PCB, PC interface

Miniature OLED Programming

User interface, OLED menu programming, embedded firmware

Fingertip Motion Sensor PCB + Control PCB

Sensor array, battery powered, haptic feedback, Bluetooth, embedded firmware, custom PCBs

Wearable Security Device

Battery powered, data encryption, Bluetooth. real-time clock, USB charging, PC software, embedded firmware, custom PCB

Wearable USB Motion Sensor

USB, real-time sensor streaming, high speed, motion sensor, embedded firmware, custom PCB

Wireless Remote Control

Bluetooth, user interface, low power, battery powered, embedded firmware, custom PCB

MRI OLED Goggles

OLED display programming, PC interface, SD card storage, eval boards, embedded firmware

Bluetooth Speaker

Audio amplifier, Bluetooth, battery powered, SD card storage, PC interface, embedded firmware, custom PCB

Display for Downloading and Viewing Data

OLED character display, user interface, menu navigation, battery powered, embedded firmware, custom PCBs

Solar Powered Motion Sensor Light

High brightness LEDs, solar panel, battery charging, motion sensor, embedded firmware, custom PCB

Motor Driver Control PCB

Wide input voltage range, H-bridge motor controller, rotary switch input, indicator LEDs, embedded firmware, custom PCB

Metal Core PCBs for High Brightness LED Spotlight

Metal core PCB assembly, thermal calculations, cable assembly, custom PCB

Battery Powered Bluetooth Motion Sensor

Battery powered, Bluetooth, real-time sensor streaming, high speed, motion sensor, embedded firmware, custom PCB

Case Studies

Successful Development of Market Ready eFoil

Electronics build for eFoil control and battery case is reaching market entry.

Project Overview

Henway Technologies has been working with the company Foil for over a year and is eager to see their product reach production in the beginning of 2020.

Foil is a high end watersports company whose headquarters is located in Pensacola, Florida.  They specialize in eFoils designed “for everyone”.  Check out more about the company on their website: https://www.getfoil.com/

Project Outcomes

Henway has had a big part in bringing this product to fruition. We designed all of the electronics that go inside the handheld controller. The controller has full color display equipped with menus and a gps to let you know your speed. It uses Qi compliant wireless charging with a custom qi compliant transmitter, bluetooth, and is completely waterproof. Inside the board in the battery case we log diagnostics of the battery management unit and the brushless dc motor. We also receive bluetooth commands from the controller and control the throttle to the motor, and we programmed all the motor control loop software in house.

Although Foil is headquartered in Florida their engineering headquarters is in Albany, New York. Because of this secondary location we have been able to do several onsite visits throughout this project to work out the fine details. It is always exciting to work with products that we know are going to make it all the way to market with our original electronics! Henway is excited to work with other companies similar to Foil in the future.

Successful Collaboration on a Bluetooth Wearables Project

Henway helps create a smart helmet to flag for concussions.
Project Overview

Henway Technologies recently took on an exciting project with Team Wendy regarding a smart helmet that can measure the amount of impact your head endures and predict the likelihood that you have a concussion and flag the system to acknowledge that you should be checked out by a medical professional.

Project Outcome

Team Wendy started out making helmets for skiing, and patented the padding they developed. From here they noticed there could be other uses for this application and they began supplying the department of defense with helmets. Then they began working to develop the previously mentioned smart helmets, and this is where Henway came in. They were debating contracting the work out but it became a no brainer when they came across us and our experience with motion sensors. Based on success in similar projects, experience working with 9-axis IMU sensor networks, and our in-house prototyping capabilities we would be a one-stop-shop for all of their outsourcing needs.

Successful Full Turnkey with VKS

Helped take VKS to the next level with the start to finish development of an Auto Advance Box.
Project Overview

Henway Technologies recently finished a specialized manufacturing project with Visual Knowledge Share (VKS).

VKS is an Electronic Work Instruction solution developed to help manufacturers throughout their assembly processes. Learn more about VKS and their capabilities from their website: https://www.vksapp.com/.

Project Outcome

Henway worked with VKS to create the Auto Advance Box for the solution. The box includes ethernet, four USB outputs, SD card data logging, ten analog inputs, and 10 outputs that can be configured as either 24 volts out or relay contacts. In addition, we wrote the PC software for configuring the behavior of the system, for rebalancing the input signal, and for configuring the network.

We took this project all the way from start to finish and are currently working on packaging the boards and sending them to VKS. What did start to finish entail?

  • Design
  • Prototyping
  • Built/Programmed 30 boards in House
  • Wrote the test procedure
  • Package and Ship to customer

At Henway we love the opportunities to create boards and work with companies throughout their entire process. We want to make the experience as easy as possible on our customers and want them to feel confident they are receiving a high quality product that works.

Successful Robotic Motor Control Project

Long term out of town motor controlled robotics for medical applications.
Project Overview

Part one of this project was centered around a medical device that is under development in a collab between firms in New York, North Carolina, and Toronto. Being out of state, there was a good amount of virtual communication involved in this project mainly through video conference.

Being a tech firm, we’re equipped with all the video conferencing tools, TV monitors, and cameras to host out of town calls and meetings easily. For this specific project, the team also came to visit us on-site and we spent the day together going over the fine details and ensuring we were delivering exactly what they were looking for.

Project Outcome

We have now perfected part one in which Henway wrote the software that drives the motor based on feedback from a 2Kg load cell, as well as the PC software to configure all the different settings of the robot such as max speed, max acceleration and deceleration, and it includes real-time graphing of both speed and torque.

The proposal for part of the project is in the works and will include the addition of custom bluetooth, wifi, custom load cell electronics, and custom cable harnesses. If everything goes as expected this will end up being a one or two year project for us.

Henway looks for projects of all different lengths of time from all different parts of the country. The robotics industry is growing every year and we are excited to be apart of the movement with this long term project with firms from different parts of the United States and abroad.

Some of Our Partners
